Tuesday, December 30, 2014

Connect the IoT Dot's with help from ConnectTheDots.io (Connect your tiny IoT devices to Azure...)



ConnectTheDots.io is an open source project by Microsoft Open Technologies created to help you get tiny devices connected to Microsoft Azure and implement great IoT solutions taking advantage of Microsoft Azure services such as Azure Stream Analytics, Machine Learning or HD Insight.

As part of the project you will find code samples, configuration scripts and guides that will help you set up tiny devices and configure Microsoft Azure services to make the most out of the data produced by your devices.

Starting with a basic scenario, the intent is to make the project grow with more devices types, more scripts to provision and configure Azure services and more "Getting Started" guides to help you implement full end to end solutions yourself.

As a first sample, we have created a simple end to end solution, from device all the way to a Website, that consists in displaying in real time on a web page raw temperature and humidity data generated from an Arduino board equipped with a weather Shield as well as alerts and processed data generated by Microsoft Azure Stream analytics based on the raw data from the device. We are using a Raspberry Pi, acting as a gateway, to send the data from the sensor up to Microsoft Azure Event Hub service. Azure Stream Analytics

Check out the Wiki to try out your first project!

Connect The Dots - Quick Start

The MS Open Tech ConnectTheDots.io project illustrates how to connect sensors and devices to the Microsoft Azure Cloud, and use Microsoft Azure to analyze and visualize the resulting data streams.

In a typical topology, sensors (here several Arduino Uno R3 boards with Arduino Weather Shields) connect to one or more local IoT Gateways (here Raspberry PI devices), which relay the data to Microsoft Azure Event Hubs. Once in the cloud, the data streams are fed into a web dashboard and to near real-time analytics engines (here Microsoft Azure Stream Analytics, in this case to generate averages and alerts across all devices). The real-time data streams, average, and alerts are then visualized in a Microsoft Azure Website, which can be viewed with any HTML5-capable browser. The high level architecture for the ConnectTheDots.IO project is shown in the figure below



I've only been doing my Coding4Fun Hardware Friday posts for how long (Hint: I start my 5th year next month) and this is the first I've seen this project. Oh sure, it's only been out a few months, but still this is a space I watch out for and I'm just now seeing this? You know what this says? Says we need more IoT blogs and shows! Funny that Channel 9 is doing just that, with the Internet of Things Show :)


[Found via Secret Microsoft Communications - IOT: Connect the dots by MS Open Tech, gets your UNO connected to the cloud!]
